No. Picture Product Name / Descriptions Select

1.

Light-duty Drawer Slides / Steel ball-bearing slide/ Drawer Slide
Model: 1701
1. 3/4-extension

2. Load capacity: 20lbs

3. Size: H17 x 16.9 (mm)

2.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 1702
1. 3/4-extension

2. Load capacity: 20lbs

3. Size: H17 x 16.9 (mm)

3.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 2700
1. 3/4-extension

2. Load capacity: 30lbs

3. Size: H27 x 26.9 (mm)

4.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 2701
1. 3/4-extension

2. Load capacity: 30lbs

3. Size: H27 (mm)

5.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 2703
1. 3/4-extension

2. Load capacity: 30lbs

3. Size: H27 (mm)

6.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 2704
1. 3/4-extension

2. Load capacity: 30lbs

3. Size: H27 (mm)

7.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3503
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

8.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3530
1. Full-extension

2. Load capacity: 50lbs

3. Size: H35 x 12.75 (mm)

4. 3-section telescopic drawer slide guarantees smooth operation

9.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3551
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

10.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3560
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 (mm)

11.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3563
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 (mm)

12.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3572B
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 (mm)

13.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3574
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

14.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3575
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

15.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3576
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

16.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3577
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 (mm)

17.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3581
1. 3/4-extension

2. Load capacity: 50lbs

3. Size: H35 x 9.5 (mm)

18.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3601
1. Full-extension

2. Load capacity: 50lbs

3. Size: H36 x 12.7 (mm)

4. W/standard hole pattern and easily disassembled w/a screwdriver

19.

Light-duty Drawer Slide / Steel ball-bearing slide
Model: 3611
1. Full-extension

2. Load capacity: 50lbs

3. Size: H36 x 12.7 (mm)
